Frame
800 Series OCLV Carbon, TQ drive system, tapered head tube, rear IsoSpeed, internal routing, flat mount disc, mudguard mounts, 142x12 mm thru axle
-
Fork
Domane+ carbon, tapered carbon steerer, internal brake routing, mudguard mounts, flat mount disc, 12x100 mm thru axle
-
Frame fit
Endurance
-
Weight
56 - 12.59 kg / 27.76 lbs (with TLR sealant, no tubes)
-
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb).
-
Battery
TQ 360Wh
-
Charger
TQ 4A charger
-
Computer
TQ LED display with Bluetooth & ANT+ connectivity
-
Motor
TQ-HPR50, 50 Nm, 250 watt maximum continuous rated power, 300 watt peak power
-
Shifter
Shimano Ultegra R8170 Di2, 12-speed
-
Front derailleur
Shimano Ultegra R8150 Di2, braze-on, down swing
-
Rear derailleur
Shimano Ultegra R8150 Di2, 34T max cog
-
Crank
Praxis Carbon, 170 mm length
-
Crank
Praxis Carbon, 172.5 mm length
-
Crank
Praxis Carbon, 175 mm length
-
Chainring
Praxis, 50/34T, 12-speed
-
Cassette
Shimano Ultegra R8101, 11-34, 12-speed
-
Chain
Shimano XT M8100, 12-speed
-
Chain
Shimano Ultegra/XT M8100, 12-speed
-
Max. chainring size
1x: 46T, 2x: 52/36
-
Wheel front
Bontrager Aeolus Pro 37, OCLV Carbon, Tubeless Ready, 37 mm rim depth, 100 x 12 mm thru axle
-
Wheel rear
Bontrager Aeolus Pro 37, OCLV Carbon, Tubeless-Ready, 37 mm rim depth, Shimano 11-speed freehub, 142x12 mm thru axle
-
Skewer front
Bontrager Switch thru-axle, removable lever
-
Skewer rear
Bontrager Switch thru-axle, removable lever
-
Tyre
Bontrager R3 Hard-Case Lite, Tubeless Ready, aramid bead, 120 tpi, 700x32 mm
-
Tyre part
Bontrager TLR sealant, 180 ml/6 oz
-
Rim strip
Bontrager TLR
-
Max tyre size
40mm without mudguards, 35mm with mudguards
-
Saddle
Verse Short Elite, hollow magnesium rails, 155 mm width
-
Saddle
Bontrager Verse Short Elite, hollow stainless steel rails, 155 mm width
-
Saddle
Verse Short Elite, hollow magnesium rails, 145 mm width
-
Saddle
Verse Short Elite, hollow stainless steel rails, 145 mm width
-
Seatpost
KVF aero carbon seat post, 20 mm offset, 280 mm length
-
Seatpost
KVF aero carbon seat post, 20 mm offset, 320 mm length
-
Handlebar
Bontrager Pro IsoCore VR-SF, 40cm
-
Handlebar
Bontrager Pro IsoCore VR-SF, 42cm
-
Handlebar
Bontrager Pro IsoCore VR-SF, 44cm
-
Handlebar tape
Bontrager Supertack Perf tape
-
Stem
Trek RCS Pro, -7-degree, 80 mm length
-
Stem
Trek RCS Pro, -7-degree, 90 mm length
-
Stem
Trek RCS Pro, -7-degree, 100 mm length
-
Stem
Trek RCS Pro, -7-degree, 110 mm length
-
Brake
Shimano Ultegra hydraulic disc, BR-R8170 flat mount caliper, resin pad w/fin
-
Brake rotor
Shimano MT800, CentreLock, 160 mm
-
Brake rotor
Shimano CL800, CentreLock, 160 mm
-
Rotor size
Max brake rotor sizes: 180mm front, 160mm rear
