Frameset | |
*Mainframe | Size:S, XL, L, M, XXL |
| OCLV Mountain Carbon, removable battery, angle-adjust headset, adjustable leverage rate, guided internal routing, interchangeable alloy rocker links, interchangeable lower shock mount, downtube guard, shuttle guard, ABP, UDH, Boost148, adaptable travel 145 mm-160 mm |
*Fork | Fox Factory 36, Float EVOL air spring, GRIP X2 damper, 44mm offset, Boost 110, 15mm Kabolt X axle, 160mm travel |
| |
*Shock | Fox Factory Float X, 205 mm x 60 mm |
| |
| |
Wheels | |
*Front Wheel | Bontrager Line Pro 30, OCLV Mountain Carbon, Tubeless Ready, 6-bolt, Boost110, 15 mm thru-axle, 29" |
*Rear Wheel | Bontrager Line Pro 30, OCLV Mountain Carbon, Tubeless Ready, Rapid Drive 108, 6-bolt, Boost148, 12 mm thru-axle, 27.5" |
| |
*Rear Skewer | Bontrager Switch thru-axle, removable lever |
*Tyre | Maxxis Assegai, tubeless-ready, 3C, EXO+ casing, MAXXGRIP, folding bead, 29x2.5'' |
| Maxxis Minion DHR II, tubeless ready, 3C, Double Down, MAXXGRIP, 27.5x2.5" |
| |
| |
*Tyre Part | Bontrager TLR sealant, 180 ml/6 oz |
| |
Max tyre size | Frame: 29x2.50", Fork: See manufacturer |
| |
E-system | |
*Battery | TQ 580Wh |
*Charger | TQ 4A charger |
| |
| |
Drivetrain | |
*Shifter | SRAM AXS pod |
| |
*Rear Derailleur | SRAM X0 Eagle AXS, T-Type |
| |
*Crank | SRAM X0 Eagle, 160 mm length |
| |
*Chain Ring | SRAM T-Type, 32T, alloy |
| |
*Cassette | SRAM Eagle XS-1295, T-Type, 10-52, 12-speed |
| |
*Chain | SRAM X0 Eagle, T-Type, 12-speed |
| |
Max. chainring size | 1x: 34T, min 30T |
| |
Components | |
*Saddle | Verse Short Pro, carbon rails, 145 mm width |
*Handlebar | Race Face ERA, carbon, 35mm, 27.5mm rise, 800mm width |
| |
*Grips | Trek Line Elite, lock-on |
*Stem | Race Face Turbine R, 35mm, 0 degree, 40mm length |
| |
*Brake | SRAM Maven Silver 4-piston hydraulic disc |
| |
*Brake Rotor | SRAM HS2, 6-bolt, 200mm |
| |
Rotor size | Max brake rotor sizes – Frame: 203 mm, min 180 mm, Fork: see fork manufacturer |
| |
Weight | |
Weight | M - 19.02 kg / 41.94 lbs (with TLR sealant, no tubes) |
Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb). |
| |
*Please note – spec applies to all sizes unless listed separately |
