Frameset | |
| *Frame | Size:M , L , S , XL |
| Alpha Platinum Aluminium, Removable Integrated Battery (RIB 2.0), tapered head tube, guided internal routing, Control Freak internal routing, Motor Armour, Boost148, 12 mm thru axle |
| *Fork | Size:S |
| SR Suntour XCR 34, air spring, 2CR damper, hydraulic lockout, tapered steerer, 44 mm offset, Boost 110, 15 mm bolt-on thru axle, 100 mm travel |
| Size:M , L , XL |
| SR Suntour XCR 34, air spring, 2CR damper, hydraulic lockout, tapered steerer, 44 mm offset, Boost 110, 15 mm bolt-on thru axle, 120 mm travel |
| |
Wheels | |
| *Front Hub | Shimano TC500 alloy, CentreLock, 110x15 mm thru axle |
| |
| *Rear Hub | Shimano TC500 alloy, CentreLock, 148x12 mm thru axle |
| |
| *Rear Skewer | Bontrager Switch thru axle, removable lever |
| *Rim | Bontrager Connection, double-wall, 32-hole, 20 mm width, Presta valve |
| Max tyre size | Frame: 29x2.50" (S: 27.5x2.50"), Fork: see manufacturer |
| |
E-system | |
| *Battery | Bosch PowerTube 800 Wh, smart system |
| |
| *Computer | Bosch Purion 200 |
| |
| *Motor | Bosch Performance Line CX, 20 mph / 32 km/h max assist (25 km/h max assist in EU and APAC) |
| |
| |
Drivetrain | |
| *Shifter | Shimano U6000, 10-speed |
| |
| *Rear Derailleur | Shimano CUES U6000 GS |
| |
| *Crank | FSA Bosch CK-220, 36T ring, 165 mm length |
| |
| *Chain Ring | FSA, 36T, steel |
| *Cassette | Shimano CUES LG300, LINKGLIDE, 11-48, 10-speed |
| |
| *Chain | Shimano LG500, 9/10/11-speed |
| |
| *Pedal | VP-536 nylon platform |
| Max. chainring size | 1x: 38T |
| |
Components | |
| *Saddle | Bontrager Commuter Comp |
| *Seatpost | Size:S |
| Bontrager alloy, 31.6 mm, 12 mm offset, 330 mm length |
| Size:M |
| Bontrager alloy, 31.6 mm, 12 mm offset, 360 mm length |
| Size:L , XL |
| Bontrager alloy, 31.6 mm, 12 mm offset, 400 mm length |
| *Handlebar | Bontrager Comp, alloy, 31.8 mm, 40mm rise, 780 mm width |
| *Grips | Trek/Bontrager XR Endurance Comp, lock-on |
| |
| *Stem | Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm length |
| *Headset | FSA IS-2, 1-1/8" top, 1.5" bottom |
| |
| *Brake Rotor | Tektro, CentreLock, 203 mm |
| |
| *Brake Set | Tektro HD-M275 hydraulic disc |
| |
| Rotor size | Max brake rotor sizes – Frame: 220 mm, min 180 mm, Fork: see fork manufacturer |
| |
Accessories | |
| *Tool | Size:M , L , S , XLBontrager Switch Lever, w/tool |
| |
Weight | |
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136kg (300lbs). |
| |
| |
| *Please note – spec applies to all sizes unless listed separately |
