Frameset | |
| *Frame | Size:M , L , S , XL |
| Alpha Platinum Aluminium, Removable Integrated Battery (RIB 2.0), tapered headtube, guided internal routing, Motor Armor, angle-adjust headset, Mino Link adjustable geometry, adjustable leverage rate, 34.9 mm seat tube, ABP, UDH, rack and mudguard mounts, Boost 148, 120 mm travel |
| *Fork | RockShox Recon Silver, Solo Air spring, Motion Control damper, lockout, tapered steerer, 42mm offset, Boost110, Maxle Stealth, mudguard mounts, 130mm travel |
| |
| *Shock | RockShox Deluxe Select R, 210x50 mm |
| |
| |
Wheels | |
| *Front Hub | Shimano TC500 alloy, CentreLock, 110x15 mm thru axle |
| |
| *Rear Hub | Shimano TC500 alloy, CentreLock, 148x12 mm thru axle |
| |
| *Rear Skewer | Size:M , L , S , XLBontrager Switch thru-axle, removable lever |
| *Rim | Size:M , L , S , XLBontrager Line TLR 30, Tubeless-Ready, 28-hole, Presta valve |
| Size:M , L , S , XLBontrager Line TLR 30, Tubeless-Ready, 32-hole, Presta valve |
| *Spokes | 14 g stainless steel, black |
| |
| *Tyre | Size:S |
| Bontrager Gunnison Pro XR, Tubeless-Ready, wire bead, 60 tpi, 27.5x2.40" |
| Size:M , L , XL |
| Bontrager Gunnison Pro XR, Tubeless Ready, dual compound, aramid bead, 60 tpi, 29x2.40" |
| *Tyre Part | Bontrager TLR sealant, 180 ml/6 oz |
| |
| *Rim Strip | Bontrager TLR |
| Max tyre size | Frame: 29x2.50" (S: 27.5x2.50"), Fork: see manufacturer |
| |
E-system | |
| *Battery | Bosch PowerTube 800 Wh, smart system |
| |
| *Charger | Bosch standard 2A, 230V, smart system |
| |
| *Computer | Bosch Purion 200 |
| |
| *Motor | Bosch Performance Line CX, 20 mph / 32 km/h max assist (25 km/h max assist in EU and APAC) |
| |
| |
Drivetrain | |
| *Shifter | Shimano U6000, 10-speed |
| |
| *Rear Derailleur | Shimano CUES U6000 GS |
| |
| *Crank | FSA Bosch CK-220, 36T ring, 165 mm length |
| |
| *Chain Ring | Size:M , L , S , XLFSA, 36T, steel |
| *Cassette | Shimano CUES LG300, LINKGLIDE, 11-48, 10-speed |
| |
| *Chain | Shimano LG500, 9/10/11-speed |
| |
| *Pedal | Size:M , L , S , XLVP-536 nylon platform |
| Max. chainring size | 1x: 38T |
| |
Components | |
| *Saddle | Bontrager Verse P3, steel rails |
| |
| *Seatpost | Size:S |
| Bontrager Line Dropper, 100mm travel, MaxFlow, internal routing, 31.6 mm, 310 mm length |
| Size:M , L , XL |
| Bontrager Line Dropper, 170 mm travel, MaxFlow, internal routing, 31.6 mm, 450 mm length |
| *Handlebar | Bontrager Comp, alloy, 31.8 mm, 40mm rise, 780 mm width |
| *Grips | Bontrager XR Trail Comp, nylon lock-on |
| |
| |
| *Stem | Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm length |
| *Headset | FSA IS-2, 1-1/8" top, 1.5" bottom |
| |
| *Brake | Tektro Gemini SL 4 piston hydraulic brake |
| |
| *Brake Rotor | Tektro, CentreLock, 203 mm |
| |
| Rotor size | Max brake rotor sizes – Frame: 220 mm, min 180 mm, Fork: see fork manufacturer |
| |
Accessories | |
| *Fender | Trek 27.5" custom fender |
| |
Weight | |
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb). |
| |
| *Please note – spec applies to all sizes unless listed separately |
