Frame
500 Series OCLV Carbon, IsoSpeed, internal storage, tapered head tube, internal cable routing, 3S chain keeper, fender mounts, flat mount disc, 142x12mm thru axle
-
Fork
Domane SL carbon, tapered carbon steerer, internal brake routing, fender mounts, flat mount disc, 12x100mm thru axle
-
Weight
56 - 8.26 kg / 18.22 lbs (with TLR sealant, no tubes)
-
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 275 pounds (125 kg).
-
Battery
Shimano BT-DN300
-
Charger
Charging cable included
-
Shifter
Shimano Ultegra R8170 Di2, 12 speed
-
Front derailleur
Shimano Ultegra R8150 Di2, braze-on, down swing
-
Rear derailleur
Shimano Ultegra R8150 Di2, 34T max cog
-
Crank
Size: 44, 47: Shimano Ultegra R8100, 50/34, 165mm length; Size: 50, 52: Shimano Ultegra R8100, 50/34, 170mm length; Size: 54, 56: Shimano Ultegra R8100, 50/34, 172.5mm length; Size: 58, 60, 62: Shimano Ultegra R8100, 50/34, 175mm length
-
Bottom bracket
Praxis, T47 threaded, internal bearing
-
Cassette
Shimano Ultegra R8101, 11-34, 12 speed
-
Chain
Shimano Ultegra/XT M8100, 12 speed
-
Max chainring size
1x: 48T, 2x: 52/36
-
Wheel front
Bontrager Aeolus Pro 37, OCLV Carbon, Tubeless Ready, 37mm rim depth, 100x12mm thru axle
-
Wheel rear
Bontrager Aeolus Pro 37, OCLV Carbon, Tubeless Ready, 37mm rim depth, Shimano 11 speed freehub, 142x12mm thru axle
-
Skewer front
Bontrager Switch thru axle, removable lever
-
Skewer rear
Bontrager Switch thru axle, removable lever
-
Tire
Bontrager R3 Hard-Case Lite, Tubeless Ready, aramid bead, 120 tpi, 700x32mm
-
Tire part
Bontrager TLR sealant, 6oz
-
Rim strip
Bontrager TLR
-
Max tire size
38mm without fenders, 35mm with fenders
-
Saddle
Size: 44, 47, 50, 52: Verse Short Elite, hollow magnesium rails, 155mm width; Size: 54, 56, 58, 60, 62: Verse Short Elite, hollow magnesium rails, 145mm width
-
Seatpost
Size: 44, 47, 50, 52, 54, 56: KVF aero carbon seatpost, 20mm offset, 280mm length; Size: 58, 60, 62: KVF aero carbon seatpost, 20mm offset, 320mm length
-
Handlebar
Size: 44, 47: Bontrager Elite IsoZone VR-SF, alloy, 31.8mm, internal Di2 routing, 75mm reach, 128mm drop, 36cm width; Size: 50: Bontrager Elite IsoZone VR-SF, alloy, 31.8mm, internal Di2 routing, 75mm reach, 128mm drop, 38cm width; Size: 52: Bontrager Elite IsoZone VR-SF, alloy, 31.8mm, internal Di2 routing, 75mm reach, 128mm drop, 40cm width; Size: 54, 56: Bontrager Elite IsoZone VR-SF, alloy, 31.8mm, internal Di2 routing, 75mm reach, 128mm drop, 42cm width; Size: 58, 60, 62: Bontrager Elite IsoZone VR-SF, alloy, 31.8mm, internal Di2 routing, 75mm reach, 128mm drop, 44cm width
-
Handlebar tape
Bontrager Supertack Perf tape
-
Stem
Size: 44: Trek RCS Pro, -7 degree, 60mm length; Size: 47: Trek RCS Pro, -7 degree, 70mm length; Size: 50: Trek RCS Pro, -7 degree, 80mm length; Size: 52, 54: Trek RCS Pro, -7 degree, 90mm length; Size: 56, 58: Trek RCS Pro, -7 degree, 100mm length; Size: 60, 62: Trek RCS Pro, -7 degree, 110mm length
-
Brake rotor
Shimano CL800, centerlock, 160mm
-
Rotor size
Max brake rotor sizes: 160mm front & rear
