| *Please note – spec applies to all sizes unless listed separately |
Frameset |
Frame |
High-performance hydroformed alloy, internal cable routing, external battery mount |
| Fork |
SR Suntour XCR32, coil spring, preload adjuster, lockout,100 mm QR, 63 mm travel |
Wheels |
Hub front |
Shimano Tourney HB-QC300, centerlock |
| Hub rear |
Shimano QC400, 32-hole, centerlock, 135x5 mm QR |
| Rim |
Bontrager Kovee, double-wall, Tubeless-Ready, 32-hole, 23 mm width, Presta valve |
| Spokes |
14 g stainless steel, black |
| Tyre |
Schwalbe G-One Allround, reflective strip, wire bead, puncture protection, 65-584 |
E-system |
Charger |
Bosch standard 4A, 230V, smart system |
| Controller |
Bosch Intuvia 100, smart system |
| Computer |
Bosch LED remote, smart system |
| Motor |
Bosch Performance Line CX, 20 mph / 32 km/h max assist (25 km/h max assist in EU and APAC) |
Drivetrain |
Shifter |
Shimano U4000, 9-speed |
| Rear derailleur |
Shimano CUES U4000 |
| *Crank |
Size:S, M |
| ProWheel alloy, 170 mm length |
Size:L |
| ProWheel alloy, 175 mm length |
| Chainring |
Alloy, with 40T narrow-wide steel ring, alloy guard |
| Cassette |
Shimano LINKGLIDE LG300, 11-46, 9-speed |
| Chain |
Shimano LG500, 9/10/11-speed |
| Pedal |
VP-536 nylon platform |
Components |
Saddle |
Selle Royal Vivo Moderate Ergo |
| Seatpost |
Bontrager alloy, 31.6 mm, 12 mm offset, 330 mm length |
| Handlebar |
Ergotec Ergo Series XXL, 31.8 mm, 30 mm rise, 16 degree sweep |
| Grips |
Bontrager XR Endurance Comp, lock-on |
| *Stem |
Size:S, M |
| Bontrager alloy, 31.8 mm clamp, adjustable rise, Blendr-compatible, 85 mm length |
Size:L |
| Bontrager alloy, 31.8 mm clamp, adjustable rise, Blendr-compatible, 105 mm length |
| Head set |
FSA Integrated, sealed cartridge bearing, 1-1/8" top, 1.5" bottom |
| Brake |
Shimano MT200 hydraulic disc |
| Brake rotor |
Shimano RT30, CentreLock, 180 mm |
Accessories |
*Light |
Size:S, L, M |
Herrmans H-Black MR5-E |
Size:S, L, M |
| Spanninga Pimento Large, with brake light |
| Cargo rack |
MIK-compatible alloy rear rack, maximum load 25 kg |
| Mudguard |
SKS plastic, rear |
Weight |
Weight |
| M - 22.20 kg (400 Wh) / 23.00 kg (545 Wh) / 23.90 kg (800 Wh) |
| Weight limit |
| This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb). |
