Frame
Size:XS , S
Alpha Platinum Aluminium, curved top tube, Removable Integrated Battery (RIB), tapered head tube, Control Freak internal routing, Motor Armour, Boost148, 12 mm thru axle
Size:M , L , XL
Alpha Platinum Aluminium, Removable Integrated Battery (RIB), tapered head tube, Control Freak internal routing, Motor Armour, Boost148, 12 mm thru axle
Fork
Size:XS
RockShox Recon Silver RL, Solo Air spring, Motion Control damper, lockout, tapered steerer, 46 mm offset, Boost110, Maxle Stealth, 80 mm travel
Size:S
RockShox Recon Silver RL, Solo Air spring, Motion Control damper, lockout, tapered steerer, 46 mm offset, Boost110, Maxle Stealth, 120 mm travel
Size:M , L , XL
RockShox Recon Silver RL, Solo Air spring, Motion Control damper, lockout, tapered steerer, 42 mm offset, Boost110, Maxle Stealth, 120 mm travel
Max compatible fork travel
120mm (526mm axle-to-crown), XS: 80mm (492mm axle-to-crown)
Hub front
Shimano MT400, CenterLock, Boost110, 15 mm thru-axle
Hub rear
Shimano MT510, CenterLock, Boost148, 12 mm thru-axle
Skewer rear
Bontrager Switch thru-axle, removable lever
Rim
Size:XS , S
Bontrager Kovee, double-wall, Tubeless Ready, 28-hole, 23 mm width, Presta valve
Size:M , L , XL
Bontrager Kovee, double-wall, Tubeless-Ready, 28-hole, 23 mm width, Presta valve
Tyre
Size:XS , S
Bontrager XR3 Comp, wire bead, 30 tpi, 27.5x2.35"
Size:M , L , XL
Bontrager XR3 Comp, wire bead, 30 tpi, 29x2.30"
Max tyre size
Frame: 29x2.60" or 27.5x2.80" (XS & S: 27.5x2.60"), Fork: See manufacturer
Shifter
Shimano Deore M6100, 12-speed
Rear derailleur
Shimano XT M8100, long cage
Crank
E*thirteen E*spec Plus, 165 mm length
Chainring
E*thirteen, 36T, steel
Cassette
Shimano Deore M6100, 10-51, 12-speed
Chain
Shimano Deore M6100
Pedal
VP-536 nylon platform
Max. chainring size
1x: 38T
Saddle
Bontrager Commuter Comp
Seatpost
Size:XS , S
Bontrager alloy, 31.6 mm, 12 mm offset, 330 mm length
Size:M
Bontrager alloy, 31.6 mm, 12 mm offset, 360 mm length
Size:L , XL
Bontrager alloy, 31.6 mm, 12 mm offset, 400 mm length
Handlebar
Bontrager alloy, 31.8 mm, 15 mm rise, 750 mm width
Grips
Bontrager XR Endurance Comp, lock-on
Stem
Size:XS
Bontrager alloy, 31.8 mm, Blendr-compatible, 7-degree, 50 mm length
Size:S , M
Bontrager alloy, 31.8 mm, Blendr-compatible, 7-degree, 60 mm length
Size:L , XL
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 70 mm length
Head set
FSA IS-2, 1-1/8" top, 1.5" bottom
Brake
Tektro HD-M745 4-piston hydraulic disc
Brake rotor
Size:XS , S
Tektro, CentreLock, 180 mm
Size:XS , S , M , L , XL
Tektro, CentreLock, 203 mm
Rotor size
Max brake rotor sizes: Front see fork manufacturer, rear 203mm
Battery
Bosch PowerTube 625Wh, smart system
Charger
Bosch standard 4A, 230V, smart system
Controller
Bosch Intuvia 100, smart system
Motor
Bosch Performance Line CX, smart system, magnesium motor body, 85 Nm
Computer
Bosch LED remote, smart system
