Frame
Alpha Platinum Aluminium, Removable Integrated Battery (RIB 2.0), tapered head tube, guided internal routing, Control Freak internal routing, Motor Armour, Boost148, 12 mm thru axle
Fork
RockShox Recon Silver RL, Solo Air, Motion Control damper, lockout, tapered steerer, 42-46 mm offset, Boost110, 15 mm Maxle Stealth, 100-120 mm travel
Hub front
Shimano TC500 alloy, CentreLock, 110x15 mm thru axle
Hub rear
Shimano TC500 alloy, CentreLock, 148x12 mm thru axle
Skewer rear
Bontrager Switch thru axle, removable lever
Rim
Bontrager Kovee, double-wall, Tubeless-Ready, 28-32 hole, 23 mm width, Presta valve
Spokes
14 g stainless steel, black
Tyre
Bontrager Gunnison Elite XR, Tubeless Ready, wire bead, 60 tpi, 27.5-29x2.40"
Rim strip
Bontrager TLR
Battery
Bosch PowerTube 800 Wh, smart system
Charger
Bosch standard 4A, 230V, smart system
Computer
Bosch Purion 200
Motor
Bosch Performance Line CX
E-bike classification
Class 1
Max assist speed
15.5 mph
Shifter
Shimano Deore M6200
Rear derailleur
Shimano Deore M8200, long cage
Crank
FSA alloy, 160 mm length
Cassette
Shimano XT M8100 or SunRace CSMZ800, 10-51 or 11-51, 12-speed
Chain
Shimano Deore M6100, 12-speed
Pedal
VP-536 nylon platform
Max chainring size
1x: 42T
Saddle
Bontrager Commuter Comp
Seatpost
TranzX JD-YSI34, 100-170 mm travel, internal routing, 31.6 mm, 350-500 mm length
Handlebar
Bontrager Comp, alloy, 31.8 mm, 40 mm rise, 780 mm width
Grips
Bontrager XR Endurance Comp, lock-on
Stem
Bontrager Rhythm Comp, 31.8 mm, 0-degree, 50 mm length
Head set
FSA IS-2, 1-1/8" top, 1.5" bottom
Brake
Shimano hydraulic disc, MT4100 lever, MT420 4-piston calliper
Brake rotor
Shimano RT64, CentreLock, 203 mm
Weight
24.10 kg/53.14 lb
Weight limit
136 kg
