Frame
Alpha Platinum Aluminium, Removable Integrated Battery (RIB 2.0), tapered head tube, guided internal routing, Control Freak internal routing, Motor Armour, Boost148, 12 mm thru axle
Fork
Fox AWL Rail, Rail 2.0 damper, tapered steerer, 44 mm offset, Boost110, 15 mm Kabolt axle, 180 mm direct mount, 100-120 mm travel, 27.5-29"
Hub front
Shimano TC500 alloy, CentreLock, 110x15 mm thru axle
Hub rear
Shimano TC500 alloy, CentreLock, 148x12 mm thru axle
Skewer rear
Bontrager Switch thru axle, removable lever
Rim
Bontrager Kovee, double-wall, Tubeless-Ready, 28-32 hole, 23 mm width, Presta valve
Spokes
14 g stainless steel, black
Tyre
Bontrager Gunnison Pro XR, Tubeless-Ready, 60 tpi, 27.5-29x2.40"
Tyre part
Bontrager TLR sealant, 180 ml/6 oz
Rim strip
Bontrager TLR
Computer
Bosch Kiox 300, Bosch LED remote, smart system
Motor
Bosch Performance Line CX
E-bike classification
Class 1
Max assist speed
15.5 mph
Shifter
SRAM Eagle 70, 12-speed
Rear derailleur
SRAM Eagle 70, T-Type
Crank
FSA alloy, 160 mm length
Cassette
SRAM Eagle XS-1270, T-Type, 10-52, 12-speed
Chain
SRAM Eagle 70, T-Type, 12-speed
Pedal
VP-536 nylon platform
Max chainring size
1x: 42T
Saddle
Bontrager Commuter Comp
Seatpost
Bontrager Line Dropper, 100-170 mm travel, MaxFlow, internal routing, 31.6 mm, 310-450 mm length
Handlebar
Bontrager Comp, alloy, 31.8 mm, 40 mm rise, 780 mm width
Grips
Bontrager XR Endurance Elite
Stem
Bontrager Rhythm Comp, 31.8 mm, 0-degree, 50 mm length
Head set
FSA IS-2, 1-1/8" top, 1.5" bottom
Brake
Shimano MT620 hydraulic disc
Brake rotor
Shimano RT64, CentreLock, 203 mm
Tool
Bontrager Switch thru axle, removable lever
Weight
23.08 kg / 50.89 lb
Weight limit
136 kg
