Frameset | |
*Frame | Size:S, XL, XS, L, M |
| Alpha Gold Aluminium, internal cable routing, rack & mudguard mounts, post mount disc, kickstand mount, 135x5mm QR |
*Fork | FX carbon, flat-mount disc, rack mounts, 410mm axle-to-crown, ThruSkew 5mm QR |
| |
Wheels | |
*Front Hub | Formula DC-20, alloy, 6-bolt, 5x100 mm QR |
| |
*Front Skewer | 139x5 mm bolt-on |
| |
*Rear Hub | Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm QR |
| 152x5 mm QR |
*Rear Skewer | |
*Rim | Bontrager Tubeless Ready Disc, 32-hole, Presta valve |
| |
*Tyre | Bontrager H2 Comp, wire bead, 30 tpi, 700x35 mm |
| |
| |
Drivetrain | |
*Shifter | Shimano CUES U6000 w/optical gear display, 10-speed |
| |
*Rear Derailleur | Shimano CUES U6000 GS |
| |
*Crank | Size:S, XS, MProwheel alloy, 40T narrow-wide ring, 170 mm length |
| Size:XL, LProwheel alloy, 40T narrow-wide ring, 175 mm length |
*Cassette | Shimano CUES LG300, LINKGLIDE, 11-48, 10-speed |
| |
*Chain | Shimano LG500 |
| |
*Pedal | Bontrager City pedals |
| |
Components | |
*Saddle | Bontrager H1 |
| |
*Seatpost | Size:S, XS, M |
| Bontrager alloy, 27.2 mm, 12 mm offset, 330 mm length |
| Size:XL, L |
| Bontrager alloy, 27.2 mm, 12 mm offset, 400 mm length |
*Handlebar | Size:S, XS, M |
| Bontrager Comp Lowriser, alloy, 31.8 mm, 15 mm rise, 600 mm width |
| Size:XL, L |
| Bontrager Comp Lowriser, alloy, 31.8 mm, 15 mm rise, 660 mm width |
*Grips | Trek Line Ergonomic Pro, lock-on |
*Stem | Size:S, XSBontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 90 mm length |
| Size:XL, L, MBontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 100 mm length |
*Brake | Shimano hydraulic disc, MT201 lever, UR300 calliper |
| |
*Brake Rotor | Shimano RT26, 6-bolt, 160 mm |
| |
| |
Weight | |
Weight | M - 11.65 kg / 25.69 lbs |
Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb). |
| |
*Please note – spec applies to all sizes unless listed separately |
