Frameset | |
| *Frame | Size:ML , M , L , S , XL |
| OCLV Mountain Carbon, IsoBow, tapered head tube, internal routing, balanced post-mount brake, Boost148 |
| *Fork | RockShox Reba RL, DebonAir, Motion Control damper, lockout, tapered steerer, 44 mm offset, Boost110, 15 mm Maxle Stealth, 120mm travel |
| |
| *Suspension Part | Bontrager Drop Lock remote |
| |
Wheels | |
| *Front Wheel | Bontrager Kovee Comp 25, Tubeless-Ready, 6-bolt, Boost110, 15 mm thru-axle, 29" |
| |
| *Rear Skewer | Bontrager Switch thru axle, removable lever |
| *Tyre | Bontrager Sainte-Anne Pro XR, Tubeless Ready, dual compound, aramid bead, 60 tpi, 29x2.40" |
| |
| *Tyre Part | Bontrager TLR sealant, 180 ml/6 oz |
| |
| *Rim Strip | Bontrager TLR |
| Max tyre size | Frame: 29x2.40", Fork: See manufacturer |
| |
Drivetrain | |
| *Shifter | SRAM Eagle 70, 12-speed |
| |
| *Rear Derailleur | SRAM Eagle 70, T-Type |
| |
| *Crank | Size:ML , M , S |
| Sram Eagle 70, T-Type, DUB, 32T, 55 mm chainline, 170 mm length |
| Size:L , XL |
| Sram Eagle 70, T-Type, DUB, 32T, 55 mm chainline, 175 mm length |
| *Bottom Bracket | SRAM DUB, 92 mm, PressFit |
| |
| *Cassette | SRAM Eagle XS-1270, T-Type,10-52, 12-speed |
| |
| *Chain | SRAM Eagle 70, T-Type, 12-speed |
| |
| Max. chainring size | 1x: 38T |
| |
Components | |
| *Saddle | Verse Short Comp, steel rails, 145 mm width |
| *Seatpost | Size:S |
| Bontrager Line Dropper, 100mm travel, MaxFlow, internal routing, 31.6 mm, 310 mm length |
| Size:ML , M , L |
| Bontrager Line Dropper, 150mm travel, MaxFlow, internal routing, 31.6 mm, 410 mm length |
| Size:XL |
| Bontrager Line Dropper, 170 mm travel, MaxFlow, internal routing, 31.6 mm, 450 mm length |
| *Handlebar | Size:SBontrager Comp, alloy, 31.8 mm, 5 mm rise, 720 mm width |
| Size:ML , M , L , XL |
| Bontrager Rhythm Comp, alloy, 31.8 mm, 15 mm rise, 750 mm width |
| *Grips | Trek Line Comp, nylon lock-on |
| *Stem | Size:SBontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm length |
| Size:ML , M |
| Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 60 mm length |
| Size:L |
| Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 70 mm length |
| Size:XL |
| Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 80 mm length |
| *Headset | FSA IS-2, 1-1/8" top, 1.5" bottom |
| |
| *Brake Rotor | SRAM CenterLine, 6-bolt, round-edge, 160 mm |
| |
| Rotor size | Max brake rotor sizes – Frame: 180 mm, Fork: see fork manufacturer |
| |
Accessories | |
| *Tool | Bontrager Switch Lever, w/tool |
| |
Weight | |
| Weight | M - 11.83 kg / 26.09 lbs (with TLR sealant, no tubes) |
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb). |
| |
| *Please note – spec applies to all sizes unless listed separately |
