Mainframe Size
S, XL, L, M, ML
Mainframe
SLR OCLV Mountain Carbon, IsoStrut, UDH, 80mm travel
Fork Size
S, XL, L, M, ML
Fork
Fox Factory 34 SL, Float EVOL air spring, GRIP SL 2- position damper, tapered steerer, 44mm offset, Boost110, 15mm Kabolt X axle, 110mm travel
Shock Size
S, XL, L, M, ML
Shock
Trek IsoStrut, RockShox SIDLuxe, 2-position remote damper
Suspension Part Size
S, XL, L, M, ML
Suspension Part
Bontrager Drop Lock remote
Front Wheel Size
S, XL, L, M, ML
Front Wheel
Bontrager Kovee Elite 30, OCLV Mountain Carbon, Tubeless Ready, 6-bolt, Boost110, 15mm thru axle, 29''
Rear Wheel Size
S, XL, L, M, ML
Rear Wheel
Bontrager Kovee Elite 30, OCLV Mountain Carbon, Tubeless Ready, Rapid Drive 108, 6 bolt, Shimano MicroSpline freehub, Boost148, 12mm thru axle, 29''
Rear Skewer Size
S, XL, L, M, ML
Rear Skewer
Bontrager Switch thru axle, removable lever
Tire Size
S, XL, L, M, ML
Tire
Maxxis Aspen, Tubeless Ready, EXO casing, folding bead, 29x2.4''
Tire Part Size
S, XL, L, M, ML
Tire Part
Bontrager TLR sealant, 6oz
Max tire size
Frame: 29x2.40", Fork: See manufacturer
Shifter Size
S, XL, L, M, ML
Shifter
Shimano XT Di2 M8250, 12 speed
Rear Derailleur Size
S, XL, L, M, ML
Rear Derailleur
Shimano XT M8250, long cage
Crank Size
S, M, ML
Crank
E*thirteen Helix Race Carbon, 34T, 55mm chainline, 170mm length
Crank Size
XL, L
Crank
E*thirteen Helix Race Carbon, 34T, 55mm chainline, 175mm length
Bottom Bracket Size
S, XL, L, M, ML
Bottom Bracket
E*thirteen BB20-92
Cassette Size
S, XL, L, M, ML
Cassette
Shimano XT M8200, 10-51, 12 speed
Chain Size
S, XL, L, M, ML
Chain
Shimano Ultegra/XT M8100, 12 speed
Max chainring size
1x: 38T, min 30T
Saddle Size
S, XL, L, M, ML
Saddle
Verse Short Elite, hollow magnesium rails, 145mm width
Seatpost Size
S
Seatpost
Bontrager Line Elite Dropper, 100mm travel, MaxFlow, internal routing, 31.6mm, 340mm length
Seatpost Size
M, ML
Seatpost
Bontrager Line Elite Dropper, 150mm travel, MaxFlow, internal routing, 31.6mm, 440mm length
Seatpost Size
XL, L
Seatpost
Bontrager Line Elite Dropper, 170mm travel, MaxFlow, internal routing, 31.6mm, 480mm length
Integrated Bar Stem Size
S, M, ML
Integrated Bar Stem
Bontrager RSL Integrated handlebar/stem, OCLV Carbon, 0mm handlebar rise, 750mm width, -13 degree stem rise, 70mm length
Integrated Bar Stem Size
L
Integrated Bar Stem
Bontrager RSL Integrated handlebar/stem, OCLV Carbon, 0mm handlebar rise, 750mm width, -13 degree stem rise, 80mm length
Integrated Bar Stem Size
XL
Integrated Bar Stem
Bontrager RSL Integrated handlebar/stem, OCLV Carbon, 0mm handlebar rise, 750mm width, -13 degree stem rise, 90mm length
Grips Size
S, XL, L, M, ML
Grips
ESI Chunky
Headset Size
S, XL, L, M, ML
Headset
FSA IS-2, 1-1/8'' top, 1.5'' bottom
Brake Size
S, XL, L, M, ML
Brake
Shimano XT M8200 4-piston hydraulic disc
Brake Rotor Size
S, XL, L, M, ML
Brake Rotor
Shimano RT86, 6-bolt, 160mm
Brake Rotor
Shimano RT86, 6-bolt, 180mm
Rotor size
Max brake rotor sizes - Frame: 160mm
Tool Size
S, XL, L, M, ML
Tool
Bontrager Switch thru axle, removable lever
Weight
M - 11.18 kg / 24.65 lbs (with TLR sealant, no tubes)
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg).
