Mainframe Size
S, XL, L, M, ML
-
Mainframe
SLR OCLV Mountain Carbon, IsoStrut, UDH, 80mm travel
-
Fork Size
S, XL, L, M, ML
-
Fork
Fox Factory 34 SL, Float EVOL air spring, GRIP SL 2- position damper, tapered steerer, 44mm offset, Boost110, 15mm Kabolt X axle, 110mm travel
-
Shock Size
S, XL, L, M, ML
-
Shock
Trek IsoStrut, RockShox SIDLuxe, 2-position remote damper
-
Suspension Part Size
S, XL, L, M, ML
-
Suspension Part
Bontrager Drop Lock remote
-
Front Wheel Size
S, XL, L, M, ML
-
Front Wheel
Bontrager Kovee Elite 30, OCLV Mountain Carbon, Tubeless Ready, 6-bolt, Boost110, 15mm thru axle, 29''
-
Rear Wheel Size
S, XL, L, M, ML
-
Rear Wheel
Bontrager Kovee Elite 30, OCLV Mountain Carbon, Tubeless Ready, Rapid Drive 108, 6 bolt, Shimano MicroSpline freehub, Boost148, 12mm thru axle, 29''
-
Rear Skewer Size
S, XL, L, M, ML
-
Rear Skewer
Bontrager Switch thru axle, removable lever
-
Tire Size
S, XL, L, M, ML
-
Tire
Maxxis Aspen, Tubeless Ready, EXO casing, folding bead, 29x2.4''
-
Tire Part Size
S, XL, L, M, ML
-
Tire Part
Bontrager TLR sealant, 6oz
-
Max tire size
Frame: 29x2.40", Fork: See manufacturer
-
Shifter Size
S, XL, L, M, ML
-
Shifter
Shimano XT Di2 M8250, 12 speed
-
Rear Derailleur Size
S, XL, L, M, ML
-
Rear Derailleur
Shimano XT M8250, long cage
-
Crank Size
S, M, ML
-
Crank
E*thirteen Helix Race Carbon, 34T, 55mm chainline, 170mm length
-
Crank Size
XL, L
-
Crank
E*thirteen Helix Race Carbon, 34T, 55mm chainline, 175mm length
-
Bottom Bracket Size
S, XL, L, M, ML
-
Bottom Bracket
E*thirteen BB20-92
-
Cassette Size
S, XL, L, M, ML
-
Cassette
Shimano XT M8200, 10-51, 12 speed
-
Chain Size
S, XL, L, M, ML
-
Chain
Shimano Ultegra/XT M8100, 12 speed
-
Max chainring size
1x: 38T, min 30T
-
Saddle Size
S, XL, L, M, ML
-
Saddle
Verse Short Elite, hollow magnesium rails, 145mm width
-
Seatpost Size
S
-
Seatpost
Bontrager Line Elite Dropper, 100mm travel, MaxFlow, internal routing, 31.6mm, 340mm length
-
Seatpost Size
M, ML
-
Seatpost
Bontrager Line Elite Dropper, 150mm travel, MaxFlow, internal routing, 31.6mm, 440mm length
-
Seatpost Size
XL, L
-
Seatpost
Bontrager Line Elite Dropper, 170mm travel, MaxFlow, internal routing, 31.6mm, 480mm length
-
Integrated Bar Stem Size
S, M, ML
-
Integrated Bar Stem
Bontrager RSL Integrated handlebar/stem, OCLV Carbon, 0mm handlebar rise, 750mm width, -13 degree stem rise, 70mm length
-
Integrated Bar Stem Size
L
-
Integrated Bar Stem
Bontrager RSL Integrated handlebar/stem, OCLV Carbon, 0mm handlebar rise, 750mm width, -13 degree stem rise, 80mm length
-
Integrated Bar Stem Size
XL
-
Integrated Bar Stem
Bontrager RSL Integrated handlebar/stem, OCLV Carbon, 0mm handlebar rise, 750mm width, -13 degree stem rise, 90mm length
-
Grips Size
S, XL, L, M, ML
-
Grips
ESI Chunky
-
Headset Size
S, XL, L, M, ML
-
Headset
FSA IS-2, 1-1/8'' top, 1.5'' bottom
-
Brake Size
S, XL, L, M, ML
-
Brake
Shimano XT M8200 4-piston hydraulic disc
-
Brake Rotor Size
S, XL, L, M, ML
-
Brake Rotor
Shimano RT86, 6-bolt, 160mm
-
Brake Rotor
Shimano RT86, 6-bolt, 180mm
-
Rotor size
Max brake rotor sizes - Frame: 160mm
-
Tool Size
S, XL, L, M, ML
-
Tool
Bontrager Switch thru axle, removable lever
-
Weight
M - 11.18 kg / 24.65 lbs (with TLR sealant, no tubes)
-
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg).
