Frame
Bianchi Infinito, Flat mount 140/160, PressFit 86.5x41 mm, Thru Axle 12x142 mm, Sram UDH compatible, Max chainring compatibility: 46-54T, Internal cable routing, Tyre clearance: ETRTO 622-40 sizes 47-50-53-55-57-59-61
Fork
Bianchi Infinito, Flat mount disc 140/160, Thru axle, OLD: 100 mm, Steerer tube diameter: 1"1/8
Headset
Acros for internal cable routing
Bottom Braceket
Shimano SM-BB71-41B, press fit type for road
Crankset
Shimano 105, FC-R7100, Hollowtech 2, 50x34T Crank length: 165 mm (47-50 cm); 170 mm (53- 55 cm); 172.5 mm (57-59 cm); 175 mm (61 cm)
Rear Derailleur
Shimano 105, RD-R7100, 12sp
Front Derailleur
Shimano 105, FD-R7100
Shift Levers
Shimano 105, shifter lever ST-R7120, caliper BRR7170
Cassette
Shimano 105, CS-R7100 11-34T, 11-12-13-14- 15-17-19-21-24-27-30-34T
Chain
Shimano CN-M6100
Brakes
Shimano BR-R7170 Hydraulic disc brake
Brake Levers
Included in the shifter
Rotors
FRONT: Shimano SM-RT54, 160 mm / REAR: Shimano SM-RT54, 160 mm
Wheels
Bianchi B 30R, alloy, internal channel width 23 mm, profile height 30 mm, 2 to 1 spoke pattern, j-bend spokes, black, HG11 body
Tyres
Pirelli P7 Sport, 35-622, 60 TPI
Stem
Bianchi AL6061, rise -7° Size: 90 mm (47-50 cm); 100 mm (53-55 cm); 110 mm (57-59 cm); 120 mm (61 cm)
Handlebars
Bianchi Compact, AL6061, diameter 31.8 mm, reach 80 mm, drop 130 mm Size: 380 mm (47-50 cm); 400 mm (53-59 cm); 420 mm (61 cm)
Grips/Tape
Bianchi Hexagon tape, 2.5 mm thickness, black
SeatPost
Bianchi Infinito, Countervail technology, full carbon, aero-flex shape length: 320 mm, 0 offset (47-55 cm); 380 mm, -20 mm offset (57-61 cm)
Seat Binder
Bianchi Custom
Saddle
Bianchi Manganese Rail, length 260 mm, width 150 mm
Part Numbers
YVB2KI478X, YVB2KI508X, YVB2KI538X, YVB2KI558X, YVB2KI578X, YVB2KI598X, YVB2KI618X
